8 PORT POE-SWITCH

HF-SS08-120W

Product Features

Product Features
≥ 8 Port 10/100Base-TX PoE ports, 2 Port 10/100Base-T uplink ports
≥ Support IEEE802.3 af/at PoE protocol, An PoE RJ45 port can supply maximum power output of 25.4W
≥ Support one-key switch to VLAN mode and 250m long distance transmission mode
≥ Support 10/100Mbps auto-negotiate
≥ Support Half/Full duplex adaptive, and auto MDI/MDI-X function
≥ All port support wire-speed forwarding
≥ Support desktop and wall-mounted installation
≥ Plug and Play, no configuration requirements
≥ Extra option: 6KV commo mode/4KV differential mode surge protection function
≥ Extra option: AI network self-healing (watchdog) function

Network Standard

IEEE 802.3 10Base-T; IEEE802.3u 100Base-TX; IEEE802.1W Spanning Tree; IEEE 802.3x flow Control

Connector Type

1×8 RJ45，1×2 RJ45

Transmission rate

10/100Mbps auto-negotiate

Transmission distance

10Base-T: ≤250m（CAT3,4,5 UTP） 100Base-TX: ≤100m（CAT3,4,5 UTP）

Forward method

Store-and-forward（full wire-speed）

Transmission mode

Half/Full duplex adaptive

MAC address table

Case space

768Kb

Jumbo frames

2048b

Packet Forwarding Rate

1.488M pps@64byte

Bandwidth

2G（non-blocking）

Power indicator

Green, PWR

Ethernet indicator

Green, per ethernet port

DIP switch indicator

Green, Extend mode.

100m

Standard mode – All ports can communicate with each other.

250m

Extend mode, port 1-8 are isolated from each other, transmission distance can up to 250m, and can communicate with port 9-10.

Input voltage

AC100~240V, 50Hz

Power consumption

Standby: ≤3W; whole: ≤96W

PoE pin

1/2+, 3/6-

The port max rate

≤25.4W

Heat dissipation method

Natural heat dissipation

Operating Temperature

-20℃～60℃

Storage Temperature

-40℃～85℃

Operating Humidity

5%～95% non-condensing
